- SMS Alerter enables you to get advance notifications through an SMS to avoid major breakdowns.
- It is fully secured and remote controlled, easy to configure and update through SMS commands.
- Ability to send messages to multiple recepients.
- Event descriptions are programmable over the air.
Specifications
| Name | Specifications |
|---|---|
| Serial Interface | |
| Interface | RS 232 (Optional Configuration Port) |
| Data Rates | 9600 |
| Characters | 8 |
| Parity | Even |
| Stop Bits | 1 |
| Flow Control | NONE |
| Network Interface | |
| Interface | GSM/GPRS |
| Protocols | SMS/FTP |
| Configuration | |
| Commands | SMS Commands |
| RS 232 | Serial Menu |
| Trigger Inputs | |
| Digital | 2 Inputs with dry contact |
| Indicators (LED) | |
| GSM | Green |
| Connect | Red |
| Receive data (RxD) | Green |
| Transmit data (TxD) | Yellow |
| Power | |
| Input | 8 to 24 V DC, 500 mA max |
| Packaging | |
| Dimensions (LxWxH) | 150g |
| Weight | 105 mm(L) x 70 mm(W) x 35 mm(H) |
| Warrant | 12 Months for Box Product |
