- EAD-02W SP allows access to data and devices from anywhere by using Wireless (Wi-fi) Technology.
- Industry-proven device server application and protocol stacks enables seamless remote access to device data, simplifying design integration, all while providing robust connectivity – including the ability to access data from any mobile device,including smartphones and tablets.
- Using the EAD-02 SP allows you to reduce your development costs, shorten your time to market, and leverage mobile solutions using one of the world’s smallest and most flexible device servers.
Specifications
| Name | Specifications |
|---|---|
| Serial Interface | |
| Interface | RS 232, RS 485 |
| Connector | 9 Pin Female for RS 232, RS 485 |
| Data Rates | 300 to 115200 bps |
| Data Bits | 7 or 8 |
| Parity | Odd, Even and No parity |
| Stop Bits | 1 or 2 |
| Flow Control | ΝΟΝΕ, ΧΟΝ/ΧOFF & RTS/CTS |
| Network Interface | |
| Interface | Ethernet 10Base-T or 100Base-TX Connector |
| Connectors | RJ 45 Female |
| Protocols | TCP, UDP, ARP, ICMP, MAC, Telnet, DHCP, HTTP SNMP & MODBUS (Optional) |
| Indicators (LED) | |
| Red | Power ON |
| Yellow | Connection Status |
| Green | Data transmitting via serial |
| Yellow | Data is receiving from serial |
| Processor | |
| CPU | ARM Cortex M4 |
| Memory | 1 MB |
| Power | |
| Input | 8 to 24 V DC |
| Environmental | |
| Operating | 0 °C to 55 °C |
| Storage | -4 °C to 66 °C |
| Packaging | |
| Dimensions (LxWxH) | 80 mm(L) x 50 mm(W) x 30 mm (H) |
| Weight | 750 g |
| Warranty | 12 Months |
